Suntree Royale BWP Grade Marine Plywood is made from 20% Gurjan and 80% Eucalyptus wood and is bonded with undiluted Phenol Formaldehyde (PF) resin which are processed through high temperature and pressure to keep the bonding intact even after 72 hours of boiling. All veneers are treated with preservatives and an additional treatment on glue line is performed with highly durable preservatives. The core veneers of this BWP quality plywood is given chemical treatment in a Vacuum Pressure Impregnation (VPT) process. The result is a Boiling Waterproof Plywood that is highly resistant to attacks from all types of microorganisms and extremely severe weather conditions. This Marine Plywood comes with IS:710-2010 and is guaranteed for 30 years against borer attacks.
| Test conducted in IS 710 Ernakulam | Minimum Value | Observed Value |
|---|---|---|
| Glue Shear Strength (after 72 hours boiling) |
Min. Ind: 800 Avg: 1000 N |
N1150N 1240N |
| Moisture Content Test | Not less than 5% | 9% |
| Adhesive of Plies | Minimum Pass Standard | Excellent |
|
Glue Shear Strength (Dry State) |
Min. Ind. 1100 N Avg. 1350 N |
1250 N 1450 N |
|
Static Bending Strength (Dry) Modulus of Rupture -Along the grain -Across the grain Modulus of Elasticity -Along the grain -Across the grain
|
Avg. 50 N/Sq.mm Avg. 30 N/Sq.mm Avg. 30 N/Sq.mm Avg. 4000 N/Sq.mm
|
63N/Sq.mm 38N/Sq.mm 9200N/Sq.mm 8295N/Sq.mm
|
|
Static Bending Strength (Wet) Modulus of Rupture -Along the grain -Across the grain -Modulus of Elasticity -Along the grain -Across the grain |
34N/Sq.mm 21N/Sq.mm 5440N/Sq.mm 2100N/Sq.mm
|
Avg. 42.00 N/Sq.mm Avg. 25.00 N/Sq.mm Avg. 84.50 N/Sq.mm
|
| Retention of Preservative Chemicals Kg/Cbm (ACC Type) | Min 12kg/cbm | Min 12.9kg/cbm |
